Standard rivet ALFO steel/steel, countersunk head | offen
Standard blind rivet ALFO®
Video with confirmation
You can watch this YouTube video directly on our website. We would like to point out that personal data (e.g. IP address) are transmitted to YouTube. Data protection .
Product details
ø 3,0 mm
| Item no.: | Shaft length: | Grip range (mm): | CAD: |
|---|---|---|---|
| 10707300060 | 6,0 | 1,5 - 3,5 mm | |
| 10707300080 | 8,0 | 3,0 - 5,5 mm | |
| 10707300100 | 10,0 | 5,0 - 7,0 mm |
- Head diameter (dk): 6,0 mm
- Mandrel diameter (dm): 1,9 mm
- Bore hole diameter: 3,1 mm
- Min. Shear strength: 1000 N
- Min. tensile strength: 1340 N
ø 3,2 mm
| Item no.: | Shaft length: | Grip range (mm): | CAD: |
|---|---|---|---|
| 10707320060 | 6,0 | 1,5 - 3,5 mm | |
| 10707320080 | 8,0 | 3,0 - 5,5 mm |
- Head diameter (dk): 6,2 mm
- Mandrel diameter (dm): 2,0 mm
- Bore hole diameter: 3,3 mm
- Min. Shear strength: 1180 N
- Min. tensile strength: 1560 N
ø 4,0 mm
| Item no.: | Shaft length: | Grip range (mm): | CAD: |
|---|---|---|---|
| 10707400060 | 6,0 | 1,5 - 3,5 mm | |
| 10707400070 | 7,0 | 2,0 - 4,5 mm | |
| 10707400080 | 8,0 | 3,0 - 5,5 mm | |
| 10707400100 | 10,0 | 5,0 - 7,0 mm | |
| 10707400120 | 12,0 | 6,5 - 9,0 mm | |
| 10707400160 | 16,0 | 8,0 - 12,5 mm |
- Head diameter (dk): 7,5 mm
- Mandrel diameter (dm): 2,3 mm
- Bore hole diameter: 4,1 mm
- Min. Shear strength: 2100 N
- Min. tensile strength: 2800 N
ø 4,8 mm
| Item no.: | Shaft length: | Grip range (mm): | CAD: |
|---|---|---|---|
| 10707480080 | 8,0 | 2,0 - 4,5 mm | |
| 10707480100 | 10,0 | 3,0 - 6,5 mm | |
| 10707480120 | 12,0 | 5,0 - 8,5 mm | |
| 10707480140 | 14,0 | 6,5 - 10,0 mm | |
| 10707480160 | 16,0 | 8,0 - 12,0 mm | |
| 10707480180 | 18,0 | 9,5 - 13,5 mm |
- Head diameter (dk): 9,0 mm
- Mandrel diameter (dm): 2,7 mm
- Bore hole diameter: 4,9 mm
- Min. Shear strength: 3180 N
- Min. tensile strength: 4220 N
ø 5,0 mm
| Item no.: | Shaft length: | Grip range (mm): | CAD: |
|---|---|---|---|
| 10707500080 | 8,0 | 2,0 - 4,5 mm | |
| 10707500100 | 10,0 | 4,0 - 6,5 mm | |
| 10707500120 | 12,0 | 6,0 - 8,5 mm | |
| 10707500160 | 16,0 | 8,0 - 12,0 mm | |
| 10707500200 | 20,0 | 11,0 - 15,5 mm | |
| 10707500250 | 25,0 | 15,0 - 20,0 mm | |
| 10707500300 | 30,0 | 19,5 - 25,0 mm |
- Head diameter (dk): 9,3 mm
- Mandrel diameter (dm): 2,9 mm
- Bore hole diameter: 5,1 mm
- Min. Shear strength: 3320 N
- Min. tensile strength: 4740 N
ø 6,4 mm
| Item no.: | Shaft length: | Grip range (mm): | CAD: |
|---|---|---|---|
| 10707640100 | 10,0 | 3,0 - 5,0 mm |
- Head diameter (dk): 13,4 mm
- Mandrel diameter (dm): 3,8 mm
- Bore hole diameter: 6,5 mm
- Min. Shear strength: 4920 N
- Min. tensile strength: 5700 N
